GRUNDFOS Zubehör Dosierpumpen Impfarmatur - Art. 95730956
Artikel-Nr.: 95730956
Teilen via
- Aktuell verfügbar
Technische Daten
Impfarmatur
Injection units connect the dosing line with the process line. They ensure a minimum counterpressure of 0.7 bar, and avoid backflow of the dosing liquid. The spring-loaded non-return valve comes with Tantal spring Injection units with ball valve are used for applications where the injection point must be closable. The ball valve is placed between the injection pipe and the spring-loaded non-return valve. Thus, the dosing line can be completely disconnected from the process. The non-return valve can be disassembled and cleaned without stopping the water flow.
Injection units connect the dosing line with the process line. They ensure a minimum counterpressure of 0.7 bar, and avoid backflow of the dosing liquid. The spring-loaded non-return valve comes with Tantal spring Injection units with ball valve are used for applications where the injection point must be closable. The ball valve is placed between the injection pipe and the spring-loaded non-return valve. Thus, the dosing line can be completely disconnected from the process. The non-return valve can be disassembled and cleaned without stopping the water flow.
| TECHNISCHE DATEN: | ||
| Pump connection: | G5/8 | |
| Version: | mit Kugelventil | |
| WERKSTOFFE: | ||
| Gehäuse: | PVC | |
| Ventilkugel: | Keramik | |
| Dichtung: | EPDM | |
| INSTALLATION: | ||
| Max. Betriebsdruck: | 16 bar | |
| Rohrverbindung: | 4/6, 6/9, 6/12, 9/12 | |
| Anschluss Ausgang: | G1/2" | |
| SONSTIGES: | ||
| Anwendungsart: | Sicherheits-/Reinigungs-/Reservesystem | |
| Herkunftsland: | DE | |
| Zolltarif Nr.: | 84818099 | |
