GRUNDFOS Zubehör Dosierpumpen Überströmventile - Art. 95730776
Artikel-Nr.: 95730776
Teilen via
- Aktuell verfügbar
Technische Daten
Überströmventile
Pressure relief valves protect the pump in case of too high counterpressure. They are installed in the discharge line near the pump, using the 2 in-line connections. The side connection leads the relief liquid back into the tank.
Pressure relief valves protect the pump in case of too high counterpressure. They are installed in the discharge line near the pump, using the 2 in-line connections. The side connection leads the relief liquid back into the tank.
| TECHNISCHE DATEN: | ||
| Pump connection: | G5/8 | |
| WERKSTOFFE: | ||
| Gehäuse: | PVDF | |
| Dichtung: | FKM/EPDM Kombi | |
| Verbindungsstück: | PVDF | |
| INSTALLATION: | ||
| Rohrverbindung: | 4/6, 6/9, 6/12, 9/12 | |
| Druckentlastung: | 16 bar | |
| SONSTIGES: | ||
| Herkunftsland: | DE | |
| Zolltarif Nr.: | 84814090 | |
